Kubernetes End-to-End Project on EKS: EKS Installation and App Deployment with Ingress

Amazon Elastic Kubernetes Service (EKS) is a fully managed Kubernetes control plane that simplifies the setup of high-availability Kubernetes clusters on AWS. This project walks you through setting up an EKS cluster, deploying an application, and configuring an Ingress controller to manage external traffic to your application.

By the end of this blog, you’ll learn:

1. How to set up an EKS cluster on AWS.

2. Install and configure prerequisites on Ubuntu.

3. Deploy an application onto the EKS cluster.

4. Configure Ingress to manage external access.

Key Concepts

1. EKS vs. Kubernetes:

   • EKS simplifies cluster management by handling the control plane, API server, etcd, and scheduler for you.

   • Kubernetes offers flexibility for both on-premises and multi-cloud deployments.

2. Ingress Controller:

   • An ingress controller is essential for routing HTTP/HTTPS traffic to your application pods.

   • In this demo, we’ll use AWS ALB Ingress Controller.

3. IAM Role Integration:

   • IAM roles can be attached to service accounts, enabling pods to securely access AWS services.

Step 1: Prerequisites Installation on Ubuntu

Before you begin, ensure you have the necessary tools installed:

1. Update the system packages

sudo apt update && sudo apt upgrade -y

2. Install AWS CLI

curl "https://awscli.amazonaws.com/awscli-exe-linux-x86_64.zip" -o "awscliv2.zip"
unzip awscliv2.zip
sudo ./aws/install
aws --version  # Verify installation

3. Install kubectl (Kubernetes CLI)

curl -LO "https://dl.k8s.io/release/$(curl -L -s https://dl.k8s.io/release/stable.txt)/bin/linux/amd64/kubectl"
sudo install -o root -g root -m 0755 kubectl /usr/local/bin/kubectl
kubectl version --client  # Verify installation

4. Install eksctl

curl -LO "https://github.com/weaveworks/eksctl/releases/download/latest_release/eksctl_$(uname -s)_amd64.tar.gz"
tar -xzf eksctl_$(uname -s)_amd64.tar.gz
sudo mv eksctl /usr/local/bin
eksctl version  # Verify installation

5. Install Helm

curl https://raw.githubusercontent.com/helm/helm/main/scripts/get-helm-3 | bash
helm version  # Verify installation

Step 2: Set Up AWS CLI

1. Configure AWS CLI

aws configure
# Provide:
# AWS Access Key ID: <your-access-key-id>
# AWS Secret Access Key: <your-secret-access-key>
# Default region name: <your-region> (e.g., us-east-1)
# Default output format: json

2. Create an IAM Role for EKS

Attach the following managed policies to your IAM role:

• AmazonEKSClusterPolicy

• AmazonEKSWorkerNodePolicy

• AmazonEKS_CNI_Policy

Step 3: Create an EKS Cluster

1. Create the EKS Cluster Using eksctl

eksctl create cluster \
  --name my-eks-cluster \
  --region us-east-1 \
  --nodes 2 \
  --node-type t3.medium \
  --with-oidc \
  --ssh-access \
  --ssh-public-key <your-ssh-key> \
  --managed

The creation process may take several minutes. Once completed, verify the cluster status:

kubectl get nodes

Step 4: Deploy an Application

1. Create a Namespace

kubectl create namespace my-app

2. Deploy the Application

Create a deployment manifest deployment.yaml:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: my-app
  namespace: my-app
spec:
  replicas: 2
  selector:
    matchLabels:
      app: my-app
  template:
    metadata:
      labels:
        app: my-app
    spec:
      containers:
      - name: my-app
        image: nginx:latest
        ports:
        - containerPort: 80

Apply the manifest:

kubectl apply -f deployment.yaml

Step 5: Expose the Application

1. Create a Service

Create a service manifest service.yaml:

apiVersion: v1
kind: Service
metadata:
  name: my-app-service
  namespace: my-app
spec:
  selector:
    app: my-app
  ports:
  - protocol: TCP
    port: 80
    targetPort: 80
  type: ClusterIP

Apply the manifest:

kubectl apply -f service.yaml

Step 6: Configure Ingress

1. Install NGINX Ingress Controller Using Helm

helm repo add ingress-nginx https://kubernetes.github.io/ingress-nginx
helm repo update
helm install ingress-nginx ingress-nginx/ingress-nginx --namespace kube-system

2. Create an Ingress Resource

Create a manifest ingress.yaml:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: my-app-ingress
  namespace: my-app
  annotations:
    nginx.ingress.kubernetes.io/rewrite-target: /
spec:
  rules:
  - host: <your-domain>
    http:
      paths:
      - path: /
        pathType: Prefix
        backend:
          service:
            name: my-app-service
            port:
              number: 80

Apply the manifest:

kubectl apply -f ingress.yaml

Step 7: Access the Application

1. Retrieve the external IP of the load balancer created by the Ingress controller:

    kubectl get ingress -n my-app


2. Open the external IP in your browser to access the application.

Step 8: Troubleshooting Common Issues

1. Check Pod Logs

kubectl logs <pod-name> -n my-app

2. Describe Resources

kubectl describe pod <pod-name> -n my-app
kubectl describe svc my-app-service -n my-app
kubectl describe ingress my-app-ingress -n my-app

3. Check Node and Cluster Status

kubectl get nodes
kubectl get events -n my-app

🏆 Outcome

• You now have a fully functional EKS cluster hosting a real-time application.

• The application is accessible via the ALB Ingress.

• Key Kubernetes concepts like pods, services, and ingress are implemented and tested.

🤔 Why Choose EKS?

• Managed Service: Reduces operational overhead.

• Integration: Seamless AWS service integration via IAM roles.

• Flexibility: Choose between EC2 and Fargate for worker nodes.

📚 Conclusion

Mastering EKS is a must for DevOps engineers. With this hands-on guide, you’ve learned how to deploy a Kubernetes cluster on AWS, expose applications via services, and route traffic using ALB ingress. Keep practicing, as Kubernetes expertise opens doors to exciting opportunities! 🚪🌟

Feel free to share your experience or questions in the comments below! 👇
